Improving Weed Control in Dry Bean Using Narrow Planting

Raptor is the most effective and currently labeled postemergence herbicide for controlling hairy nightshade and other weeds in dry beans. However, its drawback for many growers is the rotation restriction to sensitive crops such as sugar beet (Beta vulgaris L.) and potato (Solanum tuberosum L.). A need exists for season-long weed control in dry beans that is not solely dependent on herbicides. Use of integrated weed management (IWM) practices combining herbicides with cultural and mechanical control methods could allow choosing herbicide(s) with fewer or no crop rotation restrictions while still obtaining the level of control provided by Raptor.

One of the IWM methods which may help obtain successful season-long control would be enhancing the competitiveness of dry bean. Cultural practices to consider include fertilizer placement, seeding rate, time to canopy closure, row spacing, and plant architecture, i.e., growth habit, branching pattern, and plant canopy. Canadian and midwestern US studies in soybean and various classes of dry beans have shown that planting in narrow rows instead of traditional wide-row spacing improves the competitiveness of the crop against weeds (Blackshaw et al. 1999, 2000; Holmes and Sprague 2013; Rich and Renner 2009; Yelverton and Coble 1991). There also have been studies supporting the practice of higher seeding rates as a means of increasing competitiveness in narrow-row crops (Blackshaw et al. 1999, 2000; Place et al. 2009). However, growing conditions in southern Idaho are quite different from conditions in these study locations. For example, Idaho’s low humidity, semiarid climate requiring irrigation creates a much different environment than the relatively higher humidity and rainfed conditions in midwestern dry bean production areas. Therefore, Idaho studies are needed to develop appropriate IWM practices for successful, season-long control of weeds, including hairy nightshade.

∧ back to top

Description of the Studies

A row-spacing study was conducted in 2014 and 2015 at the University of Idaho (UI) Kimberly Research and Extension Center to determine the effect of row spacing, plant architecture (upright versus viny growth habit), and herbicide combinations on season-long weed control and pinto bean yield. Six weed-control treatments that included four herbicide treatments, a nontreated weedy control, and a hand-weeded control were compared for their effectiveness. Herbicides used were Basagran, Eptam, Outlook, Prowl H2O, and Sonalan in various two-way preemergence (PRE) and sequential postemergence (POST) combinations (Table 1). Two pinto bean cultivars were selected based on their plant architecture. ‘Sequoia’ has a Type II upright growth habit and ‘Othello’ has a Type III viny or trailing growth habit. The two varieties were planted in narrow rows with a grain drill in 6-inch and 7.5-inch row spacing in 2014 and 2015, respectively (Figure 1). Both varieties were planted in 22-inch wide-row spacing with a standard row crop planter (Figure 1). The seeding rate for narrow and wide-row spacing was the same at 95,000 seeds/A. Beans planted in wide-rows were cultivated twice, and the narrow-row treatments were not. Visual weed-control evaluations were conducted on four weed species present for both years of the study. Hairy nightshade, common lambsquarters (Chenopodium album L.), green foxtail (Setaria viridis L.), and redroot pigweed (Amaranthus retroflexus L.) control were rated on a 0% (no control)–100% (complete death) scale twice during the growing season: at midseason and one month later. There were no differences in weed control between 2014 and 2015, so the weed-control data were combined for both years.

^aThere was a significant interaction between weed-control treatment and row spacing for hairy nightshade control and the data are averaged across variety and year. Means followed by the same letter within each evaluation time are not statistically different using Least Square Means analysis performed at P = 0.05. Visual control was rated on a 0% (no control)–100% (completely dead) scale.
^bAll of the weed control treatments were compared to the weedy control. Basagran applications included 3.27 pt/A of Bronc Max and 1.5 pt/A of Super Spread MSO. Abbreviations: fb, followed by.
^cAll costs were based on Approximate Retail Price Per Unit of Selected Herbicides for Field Crops-CropWatch.https://cropwatch.unl.edu/2017-CW-News/2017-documents/weed-management/UNL-EC130-Herbicide-Prices.pdf, accessed May 13, 2019, and the University of Idaho Agricultural Economics publication 2017 Cost and Returns Estimate Southcentral Idaho: Magic Valley Commercial Dry Beans. EBBB3-DB-17. Cost includes adjuvants added to Basagran treatments. Application cost with a ground sprayer is $7.00/A per application and custom cultivation cost is $13.50/A per cultivation.
^dNarrow-row spacing in 2014 and 2015 was 6 and 7.5 inches, respectively. Wide-row spacing was 22 inches, both years, with one in-season cultivation.

In 2016 and 2017, another study was conducted to determine if increasing seeding rates of dry bean planted in narrow rows could increase weed control and bean yield compared to a standard seeding rate in wide rows. This also was conducted at the UI Kimberly Research and Extension Center. The variety used was ‘La Paz,’ which is an upright indeterminate Type II pinto bean. This was chosen with the intent of potentially swathing or direct harvesting the crop. The beans were planted at 100,000, 125,000, 150,000, 175,000, and 200,000 seeds/A in narrow 7.5-inch rows and at 100,000 seeds/A in wide 22-inch rows. Five weed-control treatments consisting of a nontreated weedy control, a hand-weeded control, and three herbicide treatments were included in the trial. The three herbicide treatments were Eptam + Sonalan applied PRE alone and Eptam + Sonalan applied PRE followed by sequential POST applications of Outlook or Varisto (Table 2). Like the row-spacing study, the beans planted in wide rows were cultivated twice and the beans planted in narrow rows were not cultivated. Visual weed-control evaluations of hairy nightshade, common lambsquarters, redroot pigweed, and green foxtail were conducted twice during the growing season: early (1st trifoliate growth stage) and late (two weeks after the first evaluation). The results from 2016 and 2017 are presented separately due to statistical differences in the data between years (Table 5).

^aMeans followed by the same letter within a year are not significantly different at P = 0.05 using least square means. The early weed-control evaluations were completed three and two weeks after emergence in 2016 and 2017, respectively. The late weed-control evaluations were completed seven and five weeks after emergence in 2016 and 2017, respectively.
^bAbbreviations: fb, followed by. Varisto application included 3.27 pt/A of Bronc Max and 1.5 pt/A of Super Spread MSO.

^aBean yield was averaged across variety. An interaction occurred among weed-control treatments, row spacing, and year. The data were analyzed by year. Means followed by the same letter within a year are not statistically different using a Least Square Means analysis performed at P = 0.05.
^bBasagran applications included 3.27 pt/A of Bronc Max and 1.5 pt/A of Super Spread MSO. Abbreviations: fb, followed by.
^cNarrow-row spacing in 2014 and 2015 was 6 and 7.5 inches, respectively. Wide-row spacing was 22 inches, both years.

∧ back to top

Comparing Weed Control in the Row-Spacing Study

Hairy nightshade control was influenced by row-spacing and weed-control treatment (Table 1). Averaged across the two varieties, hairy nightshade control with Eptam + Sonalan applied PRE alone to beans grown in narrow rows had the poorest control at early and late evaluations with 31% and 50% control, respectively, followed by the second-poorest control of 61% and 72%, respectively, with the same PRE-alone herbicide treatment in the wide-row spacing. The difference in control between the same herbicide treatments, but different row spacing, was most likely due to being able to cultivate in the wide but not the narrow rows. In contrast, herbicide treatments that included a POST-sequential application, in both narrow and wide rows, controlled hairy nightshade better than the PRE-only treatment. There were no differences in control among these herbicide combinations between row spacings. This suggests that, even without in-season cultivation, planting dry beans in narrow rows increases competitiveness with hairy nightshade compared with that in wide rows and can provide effective hairy nightshade control when combined with POST-sequential herbicides. This is consistent with a study in soybean, where narrow row spacing reduced weed interference and increased subsequent yield compared to wide rows (Norris et al. 2009).

Hairy nightshade control was also influenced by differences in plant architecture between the two dry bean varieties (data not shown). Averaged across herbicides and row spacing, early and late hairy nightshade control was 90% or greater in Othello compared to 86% control in Sequoia. This suggests that Othello, which has a viny, trailing growth habit, is more competitive with hairy nightshade than Sequoia, which has an upright, erect growth habit and a more open canopy.

Regardless of herbicide combinations and timings or row spacing, hairy nightshade control in the dry bean variety Othello was better than Sequoia—the variety with the more upright and open canopy. Also, when pinto bean was planted in narrow rows, competition against hairy nightshade was seemingly increased enough for control of the weed by PRE fb (followed by) POST-herbicide applications to be comparable to that in wide rows, which included cultivation.

Common lambsquarters, green foxtail, and redroot pigweed control in the row-spacing study was affected only by the weed-control treatments (Table 3). Similar to hairy nightshade control, PRE application of Eptam + Sonalan PRE alone had the poorest control of these three weed species at both evaluation dates. Otherwise, control of these three species with herbicide treatments that included a POST-sequential herbicide application was better and ranged from 83% to 94%. Common lambsquarters and redroot pigweed control with Eptam + Outlook PRE fb Sonalan + Basagran POST and redroot pigweed control with Prowl H2O + Outlook PRE fb Basagran POST was better than Eptam + Sonalan PRE fb Outlook + Basagran POST at the early and late evaluations (Table 3). Overall, the addition of a POST-sequential herbicide application to the PRE-applied herbicides was needed to provide effective season-long control of any of the four weeds in this study.

^aWeed control was averaged across variety, row spacing, and year. Means followed by the same letter within a column are not statistically different using a Least Square Means analysis performed at P = 0.05. Visual control was rated on a 0% (no control)–100% (completely dead) scale.
^bAll of the herbicide treatments were compared to the weedy control. The weedy control value (0%) was not included in the data analysis. Abbreviations: fb, followed by. All treatments with Basagran included 3.27 pt/A of Bronc Max and 1.5 pt/A of Super Spread MSO.

∧ back to top

Comparing Weed Control in the Seeding-Rate Study

There was no difference in weed control in response to dry bean seeding rates at any of the evaluation dates. Thus, weed control was compared between weed-control treatments for each year averaged across all seeding rates (Table 2). In 2016, the overall weed control in the seeding-rate experiment was poor to fair due to ineffective weed control before planting. Even though the broadleaf weed control was unacceptable (<70%) in 2016, there were still some differences between weed-control treatments. At the early and late evaluations in 2016, hairy nightshade control was better with Eptam + Sonalan applied PRE fb Varisto applied POST than Eptam + Sonalan PRE or Eptam + Sonalan PRE fb Outlook POST. At the early evaluation in 2017, there were no differences in hairy nightshade control between weed-control treatments. However, at the late evaluation, the hand-weeded control and Eptam + Sonalan PRE fb Varisto POST had better control at 93% and 95%, respectively, than Eptam + Sonalan PRE alone or Eptam + Sonalan PRE fb Outlook POST at 81% and 80% control, respectively.

There were no differences in common lambsquarters control between weed-control treatments in 2016 or at the early evaluation in 2017 (Table 2). At the late evaluation in 2017, common lambsquarters control with Eptam + Sonalan PRE fb Varisto POST was the best herbicide treatment, providing 87% control.

Redroot pigweed control at the early and late evaluation in 2016 was generally poor with all herbicide treatments, but Eptam + Sonalan PRE fb Varisto POST provided the best control (Table 4). In 2017, redroot pigweed control at the early evaluation was equal among the herbicide treatments, but at the late evaluation, redroot pigweed control was best with Eptam + Sonalan PRE fb Varisto POST at 97%.

^aMeans followed by the same letter within a year are not significantly different at P = 0.05 using least square means. The early weed-control evaluations were completed 3 and 2 weeks after emergence in 2016 and 2017, respectively. The late weed-control evaluations were completed 7 and 5 weeks after emergence in 2016 and 2017, respectively.
^bAbbreviations: fb, followed by. Varisto application included 3.27 pt/A of Bronc Max and 1.5 pt/A of Super Spread MSO.

Green foxtail control at the early evaluation in 2016 was 70% in Eptam + Sonalan PRE fb Varisto POST treatment, which was greater than the 54% recorded in the nontreated control (Table 4). At the late evaluation in 2016, green foxtail control was better with Eptam + Sonalan PRE fb Outlook POST and Eptam + Sonalan PRE fb Varisto POST at 87% and 90%, respectively, compared to Eptam + Sonalan PRE only, which averaged 58% control. At both evaluation dates in 2017, green foxtail control averaged 91% or better with the three herbicide treatments. Redroot pigweed responded similarly to the herbicide treatments as green foxtail, with the most effective herbicide sequence being Eptam + Sonalan PRE fb Varisto POST.

Averaged over all of the weed-control treatments in 2016 and 2017, weed control in dry bean planted in narrow rows was as good as the wide row spacing that was cultivated. Overall, a sequential application of Eptam + Sonalan PRE fb Varisto POST was the most effective weed-control treatment for all of the weeds in this experiment.

∧ back to top

Dry Bean Yield in Row-Spacing and Seeding-Rate Studies

Due to differences in results between the two years, bean yields were analyzed separately and are presented by year. In 2014, Eptam + Sonalan PRE alone had the lowest yield among the herbicide treatments, regardless of row spacing, compared with yields that included POST- sequential treatments which provided season-long weed control (Table 5). Eptam + Outlook PRE fb Sonalan + Basagran POST and Eptam + Sonalan PRE fb Outlook + Basagran POST in narrow rows had yields greater than Eptam + Sonalan PRE only in narrow rows. In the wide rows, all treatments with a sequential POST application had yields greater than Eptam + Sonalan PRE only. Dry bean yields in the narrow rows were statistically equal to the yield in wide row beans. The only exception was the yield in the hand-weeded control of the narrow row beans were more than 30% higher than the hand-weeded control bean in wide rows (Table 5).

In 2015, there were no yield differences between Eptam + Sonalan PRE alone and any POST-sequential treatments regardless of spacing, even with differences in weed control between these treatments. In contrast to 2014, bean yields in 2015 were higher in the narrow rows with herbicide treatments that included a POST-sequential herbicide compared to the same treatments in the wide rows. It should be noted that the weed pressure in 2015 was lower than in 2014, which meant less season-long weed competition. As a result, there were no crop yield differences between Eptam + Sonalan PRE alone and the POST-sequential treatments in 2015. This implies that when weed pressure is high, a POST-sequential application will improve weed control and subsequent yield compared with using only PRE herbicides.

In both years, the POST-sequential treatments had comparable yields and those yields were not less than that of the hand-weeded control, where weeds were controlled throughout the season. In 2015, the bean yield in the hand-weeded control was the same in both narrow and wide rows, but there were statistical yield differences between narrow and wide-row spacing with all POST-sequential treatments. The dry bean yield results from the two years of this study strongly suggest that narrow rows yield higher than wide rows. One insight gained from this study is that although the seeding rate for the narrow rows was the same as in the wide rows (95,000 seeds/A), this resulted in some gaps in the plant stand early in the growing season in the narrow rows because the grain drill randomly dropped seed, unlike a row planter which dropped seed precisely (Figures 1 and 2).

Reducing row spacing from 30 inches to anywhere between 7.5 and 15 inches has been shown to increase yields in other studies conducted across North America with several different bean classes (Blackshaw et al. 2000; Cox and Cherney 2011; Holmes and Sprague 2013). When dry beans are grown in narrow rows, using the standard harvesting practices of undercutting and windrowing beans may be eliminated if the seed pods are high enough above the ground. Narrow rows can provide the opportunity to cut beans with a swather or to direct harvest. This can reduce fuel and equipment costs, save time, and reduce or eliminate picking up dirt clods that come from undercutting the beans and that wears down harvesting equipment. However, yield loss is sometimes greater in direct harvest compared to conventional methods depending on variety, especially with varieties that produce pods close to the soil surface (Osorno et al. 2019). Beans with Type III viny growth habit would be especially prone to seed loss because of the difficulty getting the sickle bar on the header under the lowest hanging pods. Environmental conditions, equipment setup, and operator can also make a difference. Direct-harvest or swathing yield loss can be avoided or reduced with a more upright variety (Type I or II growth habit) that produces pods higher off the ground. Additionally, the use of equipment such as flexible cutterbars and pickup reels that operate closer to the soil can reduce seed loss (Orsono et al. 2013). However, there is a risk of increased weed pressure and decreased yield in upright varieties (Blackshaw et al. 1999).

As stated earlier, in the row-spacing study where two pinto bean varieties were compared, Othello with the viny or trailing growth habit yielded higher in both narrow and wide rows compared to Sequoia with the upright and open canopy (Table 6). This is in contrast to a Canadian study that demonstrated navy bean with an upright growth habit yielded higher than the viny or trailing navy bean variety in the presence of hairy nightshade (Blackshaw et al. 1999). In other words, unlike navy beans, a viny or trailing pinto bean variety was more competitive with hairy nightshade than an upright pinto bean variety. However, dry bean plant architecture has not been studied to a large extent and it is unknown how other dry bean classes or other pinto bean varieties would perform in this scenario. A viny or trailing variety may not allow direct harvest or swathing if the pods hang too close to the ground.

^aThere were no herbicide treatment or year interactions so row-spacing data were pooled across treatment and years. Means followed by the same letter are not statistically different using a Least Square Means analysis performed at P = 0.05.
^bNarrow-row spacing in 2014 and 2015 was 6 and 7.5 inches, respectively. Wide-row spacing was 22 inches, both years.

∧ back to top

Effect of Seeding Rate

In the seeding-rate study, dry bean yield in 2016 was reduced 52% when the weeds were not controlled compared to the hand-weeded control averaged across the seeding rates (Table 7). The hand-weeded control yield in 2016 was highest at 5,650 lb/A. Dry bean yield also was not different between the weedy control and the herbicide treatments in 2017.

^aThe yield data are averaged across dry bean seeding rates and are presented by year since there was a weed-control treatment by year interaction. Means followed by the same letter within a column are not statistically different using a Least Square Means analysis performed at P = 0.05.
^bVaristo application included 3.27 pt/A of Bronc Max and 1.5 pt/A of Super Spread MSO. Abbreviations: fb, followed by.

Averaged across both years and weed-control treatments of the seeding-rate study, the yield of the dry beans grown in wide rows at 100,000 seeds/A was lower than the beans grown in narrow rows at 100,000 seeds/A (Table 8).

^aThe yield data are averaged across weed-control treatments and presented by year since there was a seeding rate by year interaction. Means followed by the same letter within a column are not statistically different using a Least Square Means analysis performed at P = 0.05.
^bWide-row spacing was 22 inches. All other row spacing was 7.5 inches.

Averaged across both years in the seeding-rate study, there were no statistically significant yield differences among seeding rates in the narrow-row plots, but all had higher yields than the wide-row treatment (Table 8). Other seeding-rate studies on various classes of dry beans have shown similar results in Canada. In one study, with Ember small red bean, Blackshaw et al. (2000) found that increased seeding rates in narrow rows allowed the canopy to close earlier in the growing season, allowing the beans to intercept more light. Yields were higher when increased seeding rates were used in conjunction with narrow rows (Blackshaw et al. 2000; Malik et al. 1993).

∧ back to top

Conclusion

Season-long weed control can be achieved in edible dry bean production in Idaho with the addition of a POST-sequential application, especially in fields with high weed pressure. Furthermore, due to the increased competitiveness with weeds in narrow- versus wide-row spacing, POST-sequential applications in narrow-row beans without cultivation can control weeds as well or better than in wide-row spacing even when the POST-sequential applications are combined with cultivation. Even though POST-sequential applications increase the production cost, their subsequent increase in yield can offset the added cost, particularly in narrow-row spacing. More research on the economic feasibility of planting beans in narrow rows is needed. Dry beans grown in narrow-row spacing generally had higher yields than wide-row spacing and can become a viable option, especially with upright varieties that produce pods high enough above the soil surface to facilitate direct harvest or swathing. Increased seeding rates, from 125,000 to 150,000 seeds/A in narrow rows, can help beans compete more effectively against weeds, including common lambsquarters and redroot pigweed.

∧ back to top

References

Bertram, M.G., and P. Pedersen. 2004. Adjusting management practices using glyphosate-resistant soybean cultivars. Agronomy Journal 96: 462–68.

Blackshaw, R.E. 1991. Hairy nightshade (Solanum sarrachoides) interference in dry beans (Phaseolus vulgaris). Weed Science 39: 48–53.

Blackshaw, R.E., H.H. Muendel, and G. Saindon. 1999. Canopy architecture, row spacing and plant density effects on yield of dry bean (Phaseolus vulgaris) in the absence and presence of hairy nightshade (Solanum sarrachoides). Canadian Journal of Plant Science 79: 663–69.

Blackshaw R.E., L.J. Molnar, H.H. Muendel, G. Saindon, and X. Li. 2000. Integration of cropping practices and herbicides improves weed management in dry bean (Phaseolus vulgaris). Weed Technology 14: 327–36.

Cox, W., and J.H. Cherney. 2011. Growth and yield responses of soybean to row spacing and seeding rate. Agronomy Journal 103(1): 123–28.

Holmes, R.C., and C.L. Sprague. 2013. Row width affects weed management in type II black bean. Weed Technology 27(3): 538–46.

Idaho Bean Commission Survey. 2014. Grower Survey. Twin Falls and Nampa, ID: University of Idaho Bean School.

Malik, V.S., C.J. Swanton, and T.E. Michaels. 1993. Interaction of white bean (Phaseolus vulgaris L.) cultivars, row spacing, and seeding density with annual weeds. Weed Science 41(1): 62–68.

Norris, J.L., D.R. Shaw, and C.E. Snipes. 2009. Influence of row spacing and residual herbicides on weed control in glufosinate-resistant soybean (Glycine max). Weed Technology 16(2): 319–25.

Osorno, J., G. Endres, R. Ashley, H. Kandel, and D. Berglund. 2019. Dry bean production guide. Fargo, ND: NDSU Extension Service [accessed 2016 April 27]. https://www.ag.ndsu.edu/publications/crops/dry-bean-production-guide/a1133-20.pdf.

Place, G.T., S.C. Reberg-Horton, J.E. Dunphy, and A.N. Smith. 2009. Seeding rate effects on weed control and yield for organic soybean production. Weed Technology 23(4): 497–502.

Rich, A.M., and K.A. Renner. 2009. Row spacing and seeding rate effects on eastern black nightshade (Solanum ptycanthum) and soybean. Weed Technology 21: 124–30.

Soltani, N., J.A. Dille, R.H. Gulden, C.L. Sprague, R.K. Zollinger, D.W. Morishita, N.C. Lawrence, G.M. Sbatella, A.R. Kniss, P. Jha, and P.H. Sikkema. 2018. Potential yield loss in dry bean crops due to weeds in the United States and Canada. Weed Technology 32: 342–46. doi: 10.1017/wet.2017.116.

United States Department of Agriculture. 2018. Idaho annual statistical bulletin. National Agricultural Statistics Service, Northwest Regional Field Office. 65 p.

Yelverton, F.H., and H.D. Coble. 1991. Narrow row spacing and canopy formation reduces weed resurgence in soybeans (Glycine max). Weed Technology 5(1): 169–74.

∧ back to top

About the Authors

Kathrin D. LeQuia—Department of Plant Sciences, University of Idaho Kimberly Research and Extension Center

Michael L. Thornton—Department of Plant Sciences, University of Idaho Kimberly Research and Extension Center

Don W. Morishita—Professor Emeritus, Department of Plant Sciences, University of Idaho Kimberly Research and Extension Center

Albert T. Adjesiwor—Assistant Professor and Extension Specialist, Department of Plant Sciences, University of Idaho Kimberly Research and Extension Center
